Siegenia KFV GENIUS 2.2 PANIC - Size Variants and Dimensions

01.202010/45 H39.ELEKS014EN-00

GENIUS 2.2 PANIC, Electromechanical mul-point lock
 
K
I
F
F + 1 mm
B
G
A
C
Size
-
ants
A B C F G I K

rebate height

B001 2170 760 730 380 1020
290 130
1881 - 2170
B002 2170 760 730 380 1050
290 160
1881 - 2170
B004 2400 760 980 380 1050
270 130
2171 - 2400
B166 1855 760 730 380 952 1881 - 2170

B001 2170 760 730 380 1020
290 130
1881 - 2170
B002 2170 760 730 380 1050
290 160
1881 - 2170
B004 2400 760 980 380 1050
270 130
2171 - 2400

B002 2170 760 730 380 1050
260 160
1881 - 2170
B004 2400 760 980 380 1050
270 130
2171 - 2400
K006 1722 822.5 605 380 970 1755 - 1880
K007 1847 822.5 730 380 970 1881 - 2170

K006 1722 822.5 605 380 970 1755 - 1880
K007 1847 822.5 730 380 970 1881 - 2170
Dimensions
I + K
= can be shortened
F
= Middle of GENIUS to middle of lever
handle square spindle;
middle of magnec sensor = F + 1 mm
