Siegenia KFV GENIUS 2.2 PANIC - Cable and Wiring Diagram

01.202016/45 H39.ELEKS014EN-00

GENIUS 2.2 PANIC, Electromechanical mul-point lock
 
WARNING
-
nents
You could suer an electric shock if you touch the elec-
trical components. Flying sparks could cause a re. You
could suer life-threatening injuries caused by electric
shock or re.
• Switch o unit prior to work.
• Pull the mains plug out of the socket.
• With a xed connecon at the 230-V AC mains power
supply, switch o the safety device at the mains connec-
on.
 


5
4
3
2
1
5
4
3
2
1
5
4
3
2
1
Item Name
1
GENIUS 2.2 PANIC
2
Mul-point lock EP 9xxx
3
Access control system with SI-BUS
4
Cable transfer
5
Frame-integrated or rail nut power
supply,
voltage via SI-BUS
Item Name
1
GENIUS 2.2 PANIC
2
Mul-point lock EP 9xxx
3
Access control system (analogue)
e. g. ACS from third party producer
4
Cable transfer
5
Frame-integrated or rail nut power
supply,
voltage via analogue connecon
Item Name
1
GENIUS 2.2 PANIC
2
Mul-point lock EP 9xxx
3
Access control system with SI-BUS
4
Cable transfer
5
Frame-integrated or rail nut power
supply,
voltage via analogue connecon
