GENIUS 2.2 PANIC, Electromechanical mul-point lock
 
WARNING

Overghtening of the screws of the locking box and the
GENIUS drive could lead to sluggishness of the mechanical
system. Both could cause malfuncon and/or failure.
• Tighten the screws with 1 Nm (manually).
1
1
f
Insert the mul-point lock in the
milled door leaf.
f
Adjust the mul-point lock to
the handle spindle [1].
Ensure when you insert the GENIUS
into the routed pocket that the cable
is neither damaged nor kinked [2].
2
