Siegenia KFV GENIUS 2.2 PANIC - Via the Analogue Connection

01.202024/45 H39.ELEKS014EN-00

GENIUS 2.2 PANIC, Electromechanical mul-point lock
 
To obtain a connecon via the analogue connecon, establish a plug connecon with the KFV cable.
KFV cable Cable ID  



0
1
+
-
4
7
0 Black grey - Switchover day/night mode
1 Brown Yellow - Switchover day/night mode
+ Red White 2: + 24VDC Operang voltage (+) 24 V DC
- Blue Brown 3: - GND Operang voltage (-)
4 Yellow Green 4: input External unlocking signal
7 Violet Pink - Feedback contact
White Blue - Shield for power supply

+
1
0
-
4
7
1
2
+
-
1
0
4
7
f
Establish a plug connecon with
the KFV cable [1] and the green
PTR plug [2].
f
Tighten the screws of the PTR
plug by hand so that the wires
of the cable will not be able to
loosen themselves.
Check the rm seang.
+
-
1
0
4
7
1
+
-
1
0
4
7
f
Insert the green PTR plug [1]
into the connecon with the
designaon 0 to 7 of the GENIUS
2.2 PANIC.
f
Route the cable and connect it
to a power supply and oponally
to an analogue access control
system (see chapter 4.3).
