Siegenia KFV GENIUS 2.2 PANIC - Frame side assembly; Milling the frame for 1-sash doors

27/4527/4501.2020H39.ELEKS014EN-00

GENIUS 2.2 PANIC, Electromechanical mul-point lock
7 
 
For determinaon of posion and dimensions, see chapter 3.1.
Refer to the assembly instrucons for EE/PE inacve sash for
informaon on the frame milling for the inacve sash for 2-sash
doors.
WARNING

During milling work, there will be swarf ying around. You
could suer eye injuries.
• Wear protecve goggles.
F +1 mm
C
B
M
N
X
2
3
1

E8H striker plate: Main lock
Q striker plate: auxiliary box
E8QH: locking rail
23xx: bolt striker plate




[1] 21.0 mm
[2] 135.0 mm
[3] component depth + 1 mm
2
4
3
3
1
5
-
ing
[1] 23.0 mm
[2] 72.0 mm
[3] component depth + 1 mm
[4] 62.0 mm
[5] 16.0 mm
4
1
3
2
2
F + 1 mm
F + 1 mm
Magnets
According to the prole of the door, a
hole or milling must be carried out for
the round or oval magnets.
[1] 8.0 mm
[2] 13.0 mm
[3] 4.0 mm
[4] 17.0 mm
