GENIUS 2.2 PANIC, Electromechanical mul-point lock
1
f
Turn the two eccentric screws
[1] to the le or right up to 90°.
T 10
1.3 Nm
f
Tighten the three xing screws
of the Q adjustment rmly.
2x
f
Close the door and lock with a
double turn.
Run the conical locking elements
into the Q adjustment and laterally
press the door against the seal.
