Preparing for use
4.2 Transport and storage
Synchronous Motors 1FK7
20 Operating Instructions, 03/2011, 610.40700.40c
WARNING
Transporting and lifting the motor using its eyebolts
In the case of larger motors, eyebolts are attached to the bearing end shields or threads to
attach eyebolts.
 Eyebolts must be screwed in completely and secured by hand (approx. 8 Nm); do not
overtighten.
 Do not use deformed or damaged eyebolts.
 Do not remove the laminated fiber washers
 Loads applied transversely to the plane of the eyebolt are not permitted.
 The motor must only be lifted at the eyebolts at the bearing end shields. It is not
permissible to attach eyebolts to the shaft extension.
Figure 4-1 Lifting and transporting the motor using slings
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Siemens 1FK7 Series Specifications

General

Product type	Synchronous motor
Encoder	Incremental encoder, absolute encoder
Cooling method	Natural cooling, forced-air cooling
Degree of protection	IP64, IP65
Speed range	Up to 9000 rpm
Feedback system	Encoder or resolver
