Siemens 1FK7 Series User Manual

Description
3.2 Technical features
Synchronous Motors 1FK7
12 Operating Instructions, 03/2011, 610.40700.40c
3.2 Technical features
Table 3- 1 Technical features
Type of motor Permanent-magnet synchronous motor
Magnet material Rare-earth magnetic material
Cooling Natural cooling
Insulation of the stator winding according to EN
60034-1 (IEC 60034-1)
Temperature class 155 (F) for a winding temperature of
ΔT = 100 K at an ambient temperature of +40° C
Installation altitude (in accordance with EN 60034–1
and IEC 60034–1)
≤ 1000 m above sea level, otherwise power derating
Type of construction in accordance with EN 60034-7
(IEC 60034-7)
IM B5 (IM V1, IM V3)
Degree of protection in accordance with EN 60034-5
(IEC 60034-5)
1)
IP64; optional IP65 or IP65 + IP67 at the shaft gland
Temperature monitoring KTY 84 temperature sensor in the stator winding
Paint finish Anthracite (RAL 7016)
Drive shaft end acc. to DIN 748-3
(IEC 60072-1)
Plain shaft, optional shaft with fitted key and keyway (half-key
balancing)
Radial eccentricity, concentricity and axial eccentricity
acc. to DIN 42955 (IEC 60072–1)
2)
Tolerance N (normal)
Vibration severity grade according to EN 60034-14
(IEC 60034-14)
Grade A is maintained up to rated speed
Sound pressure level L
pA
(1 m) in accordance with
DIN EN ISO 1680, max. tolerance + 3 dB(A)
 1FK701 to 1FK704: 55 dB(A)
 1FK706: 65 dB(A)
 1FK708 to 1FK710: 70 dB(A)
Built-in encoder systems for motors without DRIVE-
CLiQ interface
 IC2048S/R
3)
incremental encoder, sin/cos 1 Vpp, 2048 S/R
3)
with C and D tracks, for SH 20 to SH 100
 AM2048P/R
3)
absolute encoder 2048 P/R
3)
, 4096 revolutions
multiturn, with EnDat interface for SH 36 to SH 100
 AM512P/R
3)
absolute encoder 512 P/R
3)
, 4096 revolutions
multiturn, with EnDat interface for SH 28
 AM16P/R
3)
absolute encoder 16 P/R
3)
, 4096 revolutions
multiturn, with EnDat interface for SH 20 and SH 28
 Resolver multi-pole (number of poles corresponds to number of
pole pairs of the motor), for SH 20 and SH 28
 2-pole resolver for SH 20 and SH 28
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Siemens 1FK7 Series Specifications

General

Product type	Synchronous motor
Encoder	Incremental encoder, absolute encoder
Cooling method	Natural cooling, forced-air cooling
Degree of protection	IP64, IP65
Speed range	Up to 9000 rpm
Feedback system	Encoder or resolver
