Operation
6.3 Configuring
3TK2810-1 safety-related speed monitor
50 System Manual, 01/2011, 926246402000 DS 02
Scenario C:
1. Parameterization:
1.1 Monitored motion: Rotational
1.2 Encoder type: Rot. encoder
1.3 Encoder selection: Encoder+E2
1.5 Encoder resolution: 512 pulses/rev.
1.6 Initiator settings:
Resolution E2 4 pulses/rev.
1.4 Increase/transmit:
Transmission: 50:1
The speed limits (rpm) to be set refer to the speed at the encoder.
Scenario D:
1. Parameterization:
1.1 Monitored motion: Rotational
1.2 Encoder type: Rot. encoder
1.3 Encoder selection: Encoder
1.5 Encoder resolution: 512 pulses/rev.
1.4 Increase/transmit:
Transmission: not relevant since only one encoder has
been selected.
The speed limits (rpm) to be set refer to the speed at the encoder.
Scenario E: Monitoring the slide to, e.g. 3 m/min.
1. Parameterization:
1.1 Monitored motion: Rotational
1.2 Encoder type: Rot. encoder
1.3 Encoder selection: Encoder+E2
1.5 Encoder resolution: 512 pulses/rev.
1.6 Initiator settings:
Resolution E2 4 pulses/rev.
1.4 Increase/transmit:
Transmission: 50:1
5RWDWLRQDO
PRQLWRULQJWKUHVKROG
7UDQVODWLRQDOPRQLWRULQJWKUHVKROG[WUDQVPLVVLRQUDWLR
,QFUHDVH
USP
PPLQ[
PPUHY
