15.1 Dimensions
The following figure indicates the dimensions of the TP27-10 with the housing
of the direct key module/control panel which is available on option.
Side view
Front view
Plan view
ÉÉ
ÉÉ
ÉÉ
ÉÉ
SIMATIC TP27
335
275
247.4
73
105
5
31
ÉÉÉÉÉÉÉÉ
ÉÉÉÉÉÉÉÉ
CPI/DKM
CPI/DKM
309.4
= option
ÉÉ
ÉÉ
The TP27-10 requires a mounting cutout (WxH) of 310
+1
mm x 248
+1
mm.
Unit dimensions
Mounting cutout
Unit Description
