7-4
TP27, TP37 Equipment Manual
Release 01/00
Print Screen ASCII (default setting):
Only ASCII characters are printed in a screen
printout (no graphics or character graphics).
An ASCII screen print is appreciably quicker
than a graphic screen print.
A screen which contains text characters be-
longing to an Asiatic character set is always
printed in graphics mode, irrespective of the
ASCII default setting.
GRAPHIC:
All elements on the screen are printed in a
screen print, including graphics, trends and bar
graphs.
Assign Color Disable individual colors (–1) or modify color
assignment.
Example:
You wish to use black (0) as the color instead
of blue (1).
Switch to the Hardcopy standard screen
(TP27-6 only).
Switch to the Assign Color standard screen
(TP27-6 only).
HELP
Call Help text
ESC
Exit from standard screen
