6-28
TP27, TP37 Equipment Manual
Release 01/00
6.6.3 “System Settings” Standard Screen
Different settings can be defined for messages using the symbolic
input fields in the System Settings standard screen. Open the
System Settings standard screen from the main screen by pressing
the adjacent button
TP27 and TP37 have different System Settings standard screens. Figure 6-12
illustrates an example of the System Settings standard screen for the TP27-10.
Fields relevant for messages are shown grey.
System Settings
Operating mode:
Display message :
Message logging:
Buffer overflow warning:
Date:
Time:
Help
ESC
Figure 6-12 System Settings standard screen for TP27-10
Only the operating elements of interest as regards messages are listed below.
See chapter 11 for a description of the other fields and buttons.
Message display FIRST
The oldest alarm message is displayed first.
LAST
The most recent alarm message is displayed
first.
Message logging ON
Alarm messages and event messages are printed
in addition to being displayed.
OFF
Alarm messages and event messages are printed
only on buffer overflow.
Purpose
Structure
Meaning of
operating elements
Messages
