8-6
TP27, TP37 Equipment Manual
Release 01/00
Selective Data Record Transmission
Recipe:
Data record name:
Comment:
Data medium:
Help
ESC
Sort order:
Figure 8-3 Input fields and buttons in standard screen Selective Data Record
Transmission (example TP37)
Transfer current values from the PLC to the main memory
of the Touch Panel (update values in the Touch Panel)
Transfer the current values from the main memory of the
Touch Panel to the PLC.
Transfer data record from the data medium to the main
memory of the Touch Panel.
Transfer data record from the main memory of the Touch
Panel to the data medium.
Select data record.
Help
Call Help text on standard screen.
ESC
Exit from standard screen
Meaning of
operating elements
Recipes
