Description, device design, dimension drawing
2.2 Connections and terminal designation
SITOP expansion modules
28 Equipment Manual, 09.2022, A5E36605235-2-76
Figure 2-13 Terminal data
2.2.2.2 SITOP PSE201U
Use copper wire certified for at least 75 °C.
Connections and terminal designations
① 24 V DC supply voltage "+", "-"
*1)
2
for square crimping, otherwise 10 mm
2
Figure 2-14 Terminal data
