Description, device design, dimension drawing
2.2 Connections and terminal designation
SITOP expansion modules
Equipment Manual, 09.2022, A5E36605235-2-76
29
2.2.3 Inrush current limiter
2.2.3.1 Logo! ICL230
Use copper cable certified for use at 90
°C.
Connections and terminal designations
Figure 2-15 Terminal data
