Installation
5.1 Input connections
SITOP expansion modules
74 Equipment Manual, 09.2022, A5E36605235-2-76
5.1 Input connections
NOTICE
Country-specific regulations must be observed when installing.
5.1.1 Redundancy modules
5.1.1.1 SITOP RED1200
Inputs "DC IN1" and "DC IN2" of the redundancy module must be connected with outputs "+"
of the power supplies.
Figure 5-1 Input/output
