Properties
1.1 2AI U HS analog electronic module (6ES7134-4FB51-0AB0)
2AI U HS analog electronic module (6ES7134-4FB51-0AB0)
Manual, 04/2007, A5E01076015-01
9
2AI U HS technical specifications (6ES7134-4FB51-0AB0)
Dimensions and weight
Width (mm) 15
Weight Approx. 40 g
Module-specific data
Supports isochronous operation Yes
Number of inputs 2
Cable length
• Shielded
Max. 200 m
Parameter length 12 bytes
(4 bytes when used as 6ES7134 4FB50-0AB0)
Address space 4 bytes
Voltages, currents, potentials
Rated load voltage L+ (from the power module) 24 VDC
• Reverse polarity protection
Yes
Galvanic isolation
• Between the channels and backplane bus
Yes
• Between the channels and load voltage L+
Yes
• Between the channels
No
Permissible potential difference
• Between the inputs and M
ANA
(U
CM
)
100 VAC
SS
• Between M
ANA
and the central grounding point
(U
ISO
)
75 VDC / 60 VAC
Insulation tested 500 VDC
Current consumption
• Power supply and load voltage L+ (no load)
Max. 35 mA
Power dissipation of the module Typically 0.8 W
Status, interrupts, diagnostics
Interrupts
• Hardware interrupt
Can be assigned parameters
1
Diagnostics function
• Group error display
Red "SF" LED
• Diagnostic information can be displayed
Possible
2
Analog value generation
Measuring principle Instantaneous value encoding
Cycle time/resolution:
• Conversion time in ms (per channel)
0,1
• Cycle time in ms (per module)
1
• Resolution (including overrange)
± 10 V/13 bits + sign
± 5 V/13 bits + sign
± 2.5 V/13 bits + sign
1 V to 5 V/13 bits
