2.2 Hardware Identification
2.2.1 Enhanced Analog Module (EAM) Identification
The Enhanced Analog Module is identified by the letters “EAM” on the bezel and by two nameplate
labels: a large label, shown here, located on the tracking plate (left side of module in Figure 1-1), and a
small label inside the bezel compartment. Access to the bezel compartment is by loosening a captive
screw in the hinged compartment cover. Both labels contain the module’s model designation, part
number, ROM version identification, and serial number. The larger label also shows the module’s current
and voltage requirements. Space is provided for additional information, such as agency certifications.
MODEL 39EAMBAN AMPS x.xxx A PN 16154-1
ROM VERSION 2.00 VOLTS 24 VDC S/N
xxxxxxxx
2.2.2 EAM Termination Strip and EAM Marshalled Termination Assembly
The EAM Termination Strip and EAM Marshalled Termination Assembly are identified by the following
information silkscreened on the component side of the appropriate assembly:
EAM EAM
ENHANCED ENHANCED
ANALOG MODULE ANALOG MODULE
MOORE PRODUCTS CO. MOORE PRODUCTS CO.
TERMINATION STRIP MARSHALLED TERMINATION
PN 16189-1 ASSEMBLY
PN 16190-1
