Maintenance SD39EAM-1r4
3-8 September 2005
3.6 EAM Termination Strip Removal/Replacement
3.6.1 Removal Procedure
Refer to Figure 2-2 and the following removal procedure:
1. As necessary, take appropriate steps to shutdown the processes monitored or controlled by the field
devices connected to the Termination Strip.
2. Remove the associated EAM from its slot in the MODULRAC. Place the EAM in a static shielded
bag for protection.
3. Disconnect signal cables from the Termination Strip.
IMPORTANT
All signal cables should be labeled for correct reconnection.
4. Loosen the Termination Strip’s captive mounting screws. Gently lift the bottom of the Board in an
arc until the board is free of its alignment pin located immediately above the "MOORE" logo. Pull
the top of the Termination Strip from the grooved backplane spacer and lift it from the MODULRAC.
3.6.2 Replacement Procedure
Refer to Figure 2-2 and the following replacement procedure:
1. Refer to section 2.4 and install the replacement Termination Strip.
2. Reconnect the signal cables.
3. Install the EAM. See section 3.5.
3.7 EAM Marshalled Termination Assembly Removal/Replacement
3.7.1 Removal Procedure
Refer to Figure 2-5 and the following removal procedure:
1. As necessary, take appropriate steps to shutdown the processes monitored or controlled by the field
devices connected to the Termination Assembly.
2. Remove the associated EAM from its slot in the MODULRAC. Place the EAM in a static shielded
bag for protection.
