Siemens APACS+ - Table 2-3 Unterminated I;O Cable

SD39EAM-1r4 Installation
September 2005 2-23
Table 2–3 Unterminated I/O Cable
J1, PIN P2, PIN WIRE/STRIPE
COLOR
WIRE
IDENT
J1, PIN P2,PIN WIRE/STRIPE
COLOR
WIRE
IDENT
A2 75 WH/BLK PWR 1 A20 56 GRN/WH PWR 10
C2 74 WH/RED VIN 1 C20 57 GRN/BLK VIN 10
E2 73 WH/BLUE COM 1 E20 41 GRN/RED COM 10
A4 65 WH/GRN PWR 2 A22 16 GRN/BLUE PWR 11
C4 49 WH/BRN VIN 2 C22 3 GRN/BRN VIN 11
E4 64 WH/OR COM 2 E22 17 GRN/OR COM 11
A6 91 WH/YEL PWR 3 A24 6 GRN/YEL PWR 12
C6 104 WH/VIO VIN 3 C24 19 GRN/VIO VIN 12
E6 0 WH/GRAY COM 3 E24 5 GRN/GRAY COM 12
A8 100 RED/WH PWR 4 A26 70 OR/WH PWR 13
C8 101 RED/BLK VIN 4 C26 71 OR/BLK VIN 13
E8 102 RED/BLUE COM 4 E26 72 OR/RED COM 13
A10 36 RED/GRN PWR 5 A28 85 OR/BLUE PWR 14
C10 47 RED/BRN VIN 5 C28 98 OR/GRN VIN 14
E10 46 RED/OR COM 5 E28 84 OR/BRN COM 14
A12 11 RED/YEL PWR 6 A30 96 OR/YEL PWR 15
C12 10 RED/VIO VIN 6 C30 94 OR/VIO VIN 15
E12 24 RED/GRAY COM 6 E30 95 OR/GRAY COM 15
A14 22 BLUE/WH PWR 7 A32 92 YEL/WH PWR 16
C14 8 BLUE/BLK VIN 7 C32 78 YEL/BLK VIN 16
E14 21 BLUE/RED COM 7 E32 79 YEL/RED COM 16
A16 14 BLUE/GRN PWR 8 Shield
Wire
1 Shield
Wire
-------
C16 27 BLUE/BRN VIN 8
E16 13 BLUE/OR COM 8
A18 44 BLUE/YEL PWR 9
C18 43 BLUE/VIO VIN 9
E18 45 BLUE/GRAY COM 9
NOTES:
1. Color for wire/stripe
