Installation SD39EAM-1r4
2-6 September 2005
• Package items to be returned in their original shipping containers. Otherwise, package it for safe
shipment or contact the factory for shipping recommendations. A module must be placed inside a
static shielding bag to protect it from electrostatic discharge.
Canadian customers:
Contact Siemens Canada.
2.4.5 Return of Equipment outside North America
Contact your Siemens Representative.
2.4.6 Equipment Handling
The EAM is completely enclosed and may be safely handled without undertaking special ESD handling
procedures provided the bezel compartment door is closed and secured. DO NOT touch the connector
pins on the back of the module. Handle the module carefully and do not subject it to excessive shock or
vibration.
CAUTION
Use a grounded wrist strap to provide ESD protection whenever the
bezel door is opened.
2.4.7 Equipment Storage
The storage temperature and humidity parameters of section 6 must be met for storage of an EAM.
2.5 EAM Termination Strip Installation
A EAM Termination Strip is to be installed at the MODULRAC slot location of each EAM when local
I/O termination is employed. As shown in Figure 2-2, a Local Termination Panel must be installed.
Refer to Figure 2-2 and the following installation procedure:
1. Consult user documentation and note the slot locations assigned to each EAM in each MODULRAC.
2. Note the following on a MODULRAC and Termination Strip:
• On a MODULRAC, locate and identify the extruded spacer to which the lower edge of the
backplane is mounted. The bottom of the extruded spacer is grooved. The top edge of a
Termination Strip will rest in this groove.
