Siemens APACS+ - Table 2-2 Channel Terminal Connections Versus Terminal Strip Number ID

Installation SD39EAM-1r4
2-22 September 2005
NOTE: For a given channel configuration, not all connections stated will be needed (e.g. a 2-wire
transmitter needs only PWR and COM connections).
*see note 7 on Figure 2-9
Table 2–2 Channel Terminal Connections Versus Terminal Strip Number ID
CHANNEL
NUMBER &
TERMINAL
TERMINAL
STRIP
NUMBER
CHANNEL
NUMBER &
TERMINAL
TERMINAL
STRIP
NUMBER
CHANNEL
NUMBER &
TERMINAL
TERMINAL
STRIP
NUMBER
CHANNEL
NUMBER &
TERMINAL
TERMINAL
STRIP
NUMBER
1-PWR 1 5-PWR 17 9-PWR 33 13-PWR 49
1-VIN 2 5-VIN 18 9-VIN 34 13-VIN 50
1-COM 3 5-COM 19 9-COM 35 13-COM 51
1-SHLD 4 5-SHLD 20 9-SHLD 36 13-SHLD 52
2-PWR 5 6-PWR 21 10-PWR 37 14-PWR 53
2-VIN 6 6-VIN 22 10-VIN 38 14-VIN 54
2-COM 7 6-COM 23 10-COM 39 14-COM 55
2-SHLD 8 6-SHLD 24 10-SHLD 40 14-SHLD 56
3-PWR 9 7-PWR 25 11-PWR 41 15-PWR 57
3-VIN 10 7-VIN 26 11-VIN 42 15-VIN 58
3-COM 11 7-COM 27 11-COM 43 15-COM 59
3-SHLD 12 7-SHLD 28 11-SHLD 44 15-SHLD 60
4-PWR 13 8-PWR 29 12-PWR 45 16-PWR 61
4-VIN 14 8-VIN 30 12-VIN 46 16-VIN 62
4-COM 15 8-COM 31 12-COM 47 16-COM 63
4-SHLD 16 8-SHLD 32 12-SHLD 48 16-SHLD 64
NOTES:
1. Table supports both the EAM Termination Strip and the EAM Marshalled Termination Assembly.
2. Channel numbers are printed on the assembly. Terminal Strip numbers (TS No) are molded into the
assembly terminals.
