Siemens APACS+ - EAM Mechanical;Electrical Specifictions; Table 6-2 EAM Specifications

Specifications SD39EAM-1r4
6-2 September 2005
6.2 EAM Mechanical/Electrical Specifictions
Table 6-2 lists the EAM’s mechanical and electrical specifications.
Table 6–2 EAM Specifications
CATEGORY SPECIFICATION DATA
Mechanical Module Weight 4.16 lbs. (1.86 Kg)
EAM Termination Strip Wire Specification
Wire Strip Length
Terminal Torque
14-22 AWG, solid or stranded
0.32" (8 mm)
3.48 in/lbs (0.6 mN)
EAM Marshalled
Termination Assy.
Wire Specification
Strip Length
Terminal Torque
10-28 AWG, solid or stranded
0.32" (8 mm)
5 in/lbs (0.86 mN)
Module Power
Dissipation
16 Analog Output Ch. @ 12 mA/Ch
16 Analog Output Ch. @ 20 mA/Ch
16 Discrete Output Ch.
15.5 watts typical
19 watts worst case
21.6 watts worst case
Module Input Voltage Voltage 24 Vdc +/- 5%
Module Operating Current Inrush Current
16 Analog Output Ch. @ 12 mA/Ch
16 Analog Output Ch. @ 20 mA/Ch
16 Discrete Output Ch.
Start Up Current
2.1 Amperes
0.64 Amperes typical
0.8 Amperes worst case
0.9 Amperes worst case
Consult Factory
Module Heat Dissipation 16 Ch. @ 12 mA/Ch
16 Ch. @ 20 mA/Ch
53 BTU/hr (15.5 watts)
63 Btu/hr (18.5 watts)
Module, General Max. Continuous Input
Field Power Source
Linearity
Scan Rate
Input Impedance
Common Mode Rejection
+/- 30 Vdc all channels
24 Vdc
0.025% of span
20 mS minimun
> 2 Megaohms @ < 10 Hz
120 dB @ 50/60 Hz
Module Channels Number of Channels
Dielectric Strength
16 (each configurable)
Tested to 1950 Vdc for 2 seconds channel to channel and all
channels to ground
Module Analog Input Current Input Range
Voltage Input Range
Resolution
Accuracy
Repeatability
0-20 mA or 4-2 mA
0-5 Vdc or 1-5 Vdc
13, 14, 15, or 16 bits
+/- 0.025% of span
+/-0.003% of span @ 16 bits
Module Analog Output Current Input Range
Resolution
Accuracy
Repeatability
Load Limits
0-21 mA or 3.2-20.8 mA
14 bits
0.1% of span
+/- 0.018% of span
50 to 800 ohms
Module Frequency Input Freqency Range
Current Input Threshold
Resolution
Accuracy
Repeatability
0.0000858 to 46080 Hz
10 mA +/- 1 mA
10, 12, 14, or 16 bits
+/- 0.012% of span @ 16 bits
+/- 0.002% @ 16 bits
