Siemens APACS+ - Model Designation; Accessories; Table 5-1 EAM Accessories

SD39EAM-1r4 Model Designation
September 2005 5-1
5 Model Designation
Refer to the following to decode the model designation:
39EAM B A N Enhanced Analog Module (EAM)
│ │ └── Electrical Approvals: N = Not Required
│ └──── Design Level: A = Current Design
└────── 4-mation Version: B=2.00, 2.01, 2.02, 2.03, 2.06, C=3.00 and later
5.1 Accessories
Table 5-1 lists the available EAM accessories.
Table 5–1 EAM Accessories
PART NUMBER DESCRIPTION
16114-97 Marshalling Utility Panel (Figure 2-4)
Includes installed wire ducts and DIN rails for mounting APACS marshalled
termination assemblies. For installation in an APACS MODULPAC cabinet.
16114-12 Blank Utility Panel (Figure 2-4)
Similar to above but without installed ducts and rails. For installation in an
APACS MODULPAC cabinet.
16056-468 End Stop Kit. End Stops prevent the sliding of an EAM Marshalled
Termination Assembly along the mounting DIN rail.
16056-562
(single piece number)
Mounting Ear (Figure 2-6). Provides for a flat mounting of the EAM
Marshalled Termination Assy. Four pieces required. Refer to section 2.6.2.
