SD39EAM-1r4 Installation

September 2005 2-7

• Identify ten alignment pins located below the MODULRAC frame that span the width of the

MODULRAC panel. One of these pins will engage a hole located on the Termination Strip

above the MOORE logo. The left-most pin corresponds to MODULRAC slot #1.

• The Termination Strip’s captive mounting screws can be seen projecting from the bottom of the

plastic extrusion panel.
