Siemens ARCADIS Orbic - Terminal Wiring and Assembly Insertion

Siemens AG SPR2-320.814.02.01.02 ARCADIS Orbic
01.05 CS SD 24
3D Reconstruction Upgrade Part 1 23
Page 23 of 46
Medical Solutions
• Attach the hexagonal bolts (see (Fig. 15 / p. 23)).
• Place D200 on the hexagonal bolts.
• Attach D200 with the contact washers and nuts (Fig. 16 / p. 24).
Fig. 15: Mounted bolt
