Pan/Tilt and Telemetry Equipment
Pan/Tilt Mounts
4-13© Siemens Building Technologies Group
4
Type Order No.
WMB-PT40
Wall Mount Bracket for PT40 and CDD2410
Medium-duty aluminium wall mount with integral swivel-tilt joint. The
housing position is secured with a single allen-screw. Four fixtures
holes enable stable mounting on flat surfaces. Provided complete with
stainless-steel fixings to attach the housing to the mount.
Finish Galvanized steel‚ painted
Colour Off-white (RAL9002)
Load rating 60 kg
Arm length 226 mm
Dimensions (W x H x D) 250 x 290/430 x 530 mm
Weight 2.40 kg
2GF1710-8AC
P25-SMKIT
Side Mount Plate for Pan-Tilt Range P25
The side mount plate can be used to convert a P/T P25 over-the-top
mount version to a side mount version.
Colour Painted Polyester Powdercoat
RAL7032 Leatherette Full Gloss
Weight 1.0 kg
BPZ:80-353
BP40
40 kg Fixed Bracket
A medium-weight bracket for mounting medium-weight pan & tilts
and/or housings to a wall or other surface.
Dimensions (W x H x D) 4" PCD Mounting Holes‚ 460 mm
Long.
Colour Painted Polyester Powdercoat
RAL7032 Leatherette Full Gloss
Load rating 40 kg
Finish Cast Aluminium
Weight 2.0 kg
BPZ:80-111
BP100
Heavy-Duty Fabricated Bracket
A heavy-duty bracket for fixing heavy housings and/or pan & tilts to a
wall or other surface.
Dimensions (W x H x D) 230 x 420 x 664 mm
Colour Polyester Powdercoat RAL7032
Leatherette Full Gloss
Load rating 100 kg
Finish Tubular Square Section Stainless
Steel
Weight 8.0 kg
BPZ:80-110
