Pan/Tilt and Telemetry Equipment
Pan/Tilt Heads
4-4 © Siemens Building Technologies Group
Type Order No.
P25/D
P25/D Pan & Tilt Head‚ 24 V DC
A robust‚ high-performance side mount DC Pan-Tilt unit. Allows reliable
and accurate control of medium-heavy loads up to 25 kg‚ with thermo-
static heater. Includes pre-wired cables (2 m long).
Power requirements 24 V DC
Colour Painted Polyester Powdercoat
RAL7032 Leatherette Full Gloss
Dimensions (W x H x D) Side mount:
380 x 230 x 184 mm
Plug connection 7-pin plug (power supply)
Pan speed 24°/s
Tilt speed 12°/s
Load rating 25 kg (Side mount)
Presets No
Protection rating IP66
Weight 7.0 kg
BPZ:80-185
P25T/D
P25T/D Pan & Tilt head‚ 24 V DC
A robust‚ high-performance over-the-top mount DC Pan-Tilt unit (side
mount optional). Allows reliable and accurate control of medium-heavy
loads from 16 kg‚ with thermostatic heater. Includes pre-wired cables
(2 m long).
Power requirements 24 V DC
Colour Painted Polyester Powdercoat
RAL7032 Leatherette Full Gloss
Dimensions (W x H x D) Side mount:
380 x 230 x 184 mm
Over the top mount:
221 x 252 x 184 mm
Plug connection 7-pin plug (power supply)
Pan speed 48°/s
Tilt speed 24°/s
Load rating 16 kg (Over the Top) or
16 kg (Side mount)
Presets No
Protection rating IP66
Weight 7.0 kg
BPZ:80-350
