Siemens CRT

Lenses
Varifocal Length Lenses
2-5© Siemens Building Technologies Group
2
Type Order No.
CLVM13..
Manual Iris
Lens with high-performance glass optics for compact size with manual
iris. Focal length and focus adjustments have screw-locks to ensure
views remain as initially set. Supplied with fitted plug.
The technical details of these lenses are listed below:
CLVM13..
CLVM1314/3.5-8
3.5 D 8 mm F1.4 1/3 CS
Format 1/3" CS-mount
Focal length 3.5 D 8 mm
Focus type Adjustable
Maximum relative aperture F1.4
Horizontal angle of view 35 D 73.8°
Minimum object distance 0.3 m
Weight 0.0898 kg
2GF1664-8AG
CLVM1314/2.5-10
2.5 D 10 mm F1.4 1/3 CS
Format 1/3" CS-mount
Focal length 2.5 D 10 mm
Focus type Adjustable
Maximum relative aperture F1.4
Horizontal angle of view 28.3 D 105.8°
Minimum object distance 0.3 m
Weight 0.0808 kg
2GF1664-8AK
CLVM1325/5-50
Manual Iris
Focal length 5 D 50 mm
Focus type Adjustable
Maximum relative aperture F1.4 D C
Horizontal angle of view 5.6 D 53.6°
Minimum object distance 0.3 m
Weight 0.20 kg
2GF1664-8AN
CLVM1318/7-70
7 D 70 mm F1.8 1/3" CS
Format 1/3" CS-mount
Focal length 7 D 70 mm
Focus type Adjustable
Maximum relative aperture F1.8
Horizontal angle of view 4.2 D 40.1°
Minimum object distance 0.3 D 1.0 m
Weight 0.1995 kg
2GF1664-8AJ
