Pan/Tilt and Telemetry Equipment
Pan/Tilt Telemetry Receivers/Drivers
4-7© Siemens Building Technologies Group
4
Type Order No.
CDC0501
Telemetry Receiver for Control Pan-Tilt Heads
Weatherproof telemetry receiver for control pan-tilt units and motor-
driven zoom lenses. 3 auxilliary contacts are available to trigger exter-
nal devices. The drivers can be controlled either via a SIMATRIX SYS‚
Neo‚ 648 or 164 video matrix or from the CKA3210 and CKA4820 con-
trol keyboards directly. The control unit is designed for operating pan-
and-tilt heads with a power supply of 230 V AC‚ 115 V AC or 24 V AC.
Up to 99 addresses can be selected using DIP switches.
6 x M16‚ 2 x M20 and 1 x M26 glands are provided for cabling.
Address codes 99
Power requirements 230 V AC / 115 V AC‚ 50/60 Hz
Dimensions (W x H x D) 280 x 190 x 130 mm
Auxiliary relays 3
Compatible with CKA3210‚ CKA4820‚ SIMATRIX
Protection rating IP66
Telemetry formats TTY 20 mA‚ RS232‚ RS422 / RS485
Auxiliary contact rating 250 V AC‚ 1 A
30 V DC‚ 2.5 A
Baud rate (2400 to 19200 bps selectable)
Data outputs (camera control) TTL‚ RS422 / RS485
Weight 2.85 kg
S24245-B5015-A1
CDC0502
Telemetry Receiver for Control Pan-Tilt Heads‚ Potentiometers
Weatherproof telemetry receiver for control pan-tilt units and motor-
driven zoom lenses. The drivers can be controlled either via a SIMATRIX
SYS‚ Neo‚ 648 or 164 video matrix or from the CKA3210 and CKA4820
control keyboards directly. The control unit is designed for operating
pan-and-tilt heads with a power supply of 230 V AC‚ 115 V AC or 24 V
AC. Up to 99 addresses can be selected using DIP switches. Also with
position control for zoom/focus and pan/tilt for 64 stored preset posi-
tions.
6 x M16‚ 2 x M20 and 1 x M26 glands are provided for cabling.
Address codes 99
Power requirements 230 V AC‚ 115 V AC‚ 50/60 Hz
Dimensions (W x H x D) 280 x 190 x 130 mm
Auxiliary relays 3
Compatible with CKA3210‚ CKA4820‚ SIMATRIX
Protection rating IP66
Telemetry formats TTY 20 mA‚ RS232‚ RS422 / RS485
Auxiliary contact rating 250 V AC‚ 1 A
30 V DC‚ 2.5 A
Baud rate (2400 to 19200 bps selectable)
Data outputs (camera control) TTL‚ RS422 / RS485
Presets 64
Weight 2.85 kg
S24245-B5017-A1
