Quads‚ Split Screens and Video Distribution
Monochrome and Colour Quads
9-2 © Siemens Building Technologies Group
Type Order No.
VQD100-RT
Monochrome Quad Real-Time 12 V DC
Simple‚ cost-effective surveillance solution for small systems of up to
four cameras. An intuitive user interface enables manual or automatic
sequencing of all connected cameras in full-screen and quad format.
Camera inputs 4 x BNC‚ 75 Ohm
Monitor display Real-time quad / full screen
VCR output Yes
Sequencing Quad‚ cameras 1 z 4
Dwell time Adjustable 0 z 99 s
Resolution 720 (H) x 576 (V) pixels
Alarm inputs 1 per camera
Alarm output relay 1 x Form-C (C‚ NO‚ NC)‚ 24 V DC‚ 1 A
Dimensions (W x H x D) 285 x 44 x 235 mm
Weight 1.70 kg
Power requirements 12 D 24 V AC / DC (230 V AC adapter
supplied)
2GF2001-8AE
VQD300-RT
Colour Quad Real-Time 12 V DC
Simple‚ cost-effective surveillance solution for small systems of up to
four cameras. An intuitive user interface enables manual or automatic
sequencing of all connected cameras in full-screen and quad format.
Monitor display Real-time quad / full screen
VCR output Yes
Sequencing Quad‚ cameras 1 z 4
Dwell time Adjustable 0 z 99 s
Resolution 720 (H) x 576 (V) pixels
Video inputs 4 x BNC‚ 75 Ohm
Alarm inputs 1 per camera
Alarm output relay 1 x Form-C (C‚ NO‚ NC)‚ 24 V DC‚ 1 A
Dimensions (W x H x D) 285 x 44 x 235 mm
Weight 1.70 kg
Power requirements 12 D 24 V AC / DC (230 V AC adapter
supplied)
2GF2001-8AF
