Cameras and Domes
Fixed Domes
1-24 © Siemens Building Technologies Group
Type Order No.
CFFB1310..
1/3" CCD 3.7 mm Monochrome Fixed Dome
Attractive‚ standard resolution‚ ceiling-mount monochrome dome cam-
era complete with clear protective bubble. Includes service monitor
connection and cable for local‚ easy setup. Designed for indoor applica-
tions where discreet‚ unobtrusive surveillance is demanded.
Horizontal resolution 400 TV lines
Minimum illumination 0.13 Lux (F2.0 @50IRE)
Gain control AGC (ON/OFF)
S/N ratio > 50 dB
Lens 3.7 mm‚ F2.0
Electronic shutter (AES) Autom 1/50 to 1/100K s
Horizontal angle of view 70°
Minimum object distance 0.2 m
Bubble type Clear
Backlight compensation (ON/OFF)
Local service monitor connector 2-pin (1 m BNC cable included)
Dimensions (Ø x H) 112 x 97.5 mm
Power requirements 12 V DC / 24 V AC
Power consumption 3 W
Weight 0.29 kg
CFFB1310..
CFFB1310-LC
1/3" CCD 3.7 mm Monochrome Fixed Dome 400 TVL‚ CCIR
As CFFB1310.. for technical details‚ but with the following differences:
Television standard CCIR: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 500 (H) x 582 (V)
2GF1084-8AC
CFFB1310-LE
1/3" CCD 3.7 mm Monochrome Fixed Dome 400 TVL‚ EIA
As CFFB1310.. for technical details‚ but with the following differences:
Television standard EIA: 525 lines‚ 60 fields‚
60 Hz (vertically)‚
15.734 Hz (horizontally)
Pixels 510 (H) x 492 (V)
2GF1084-8AD
