Type Order No.
CCDA1435..
1/4'' CCD High-Speed Dome‚ Indoor 24 V AC
The CCDA1435 dome range delivers the standard features of a pro-
grammable dome‚ but is priced comparably to a PTZ. This provides an
alternative for customers who prefer the convenience and programma-
bility of a dome camera‚ but previously considered domes to be price-
prohibitive. Choose from several innovative mounting options‚ includ-
ing hard ceiling and flush mount ceiling brackets‚ wall mount brackets
and different bubble colours. As The dome contains all the necessary
installation components‚ so installation is fast - just 15 minutes from
box to ceiling for the hard ceiling mount. The dome‘s power-on diag-
nostics and functional tests assist with fault isolation during installation
and service. The dome accommodates a variety of protocols‚ including
the Siemens protocol. The dome is available as a simple colour camera‚
light-sensitive low-light camera or flexible‚ day-night camera with 18 x
and 26 x optical zoom and 480 TV lines resolution‚ providing a quality‚
high resolution picture. The dome also provides user-programmable
presets and patterns‚ one alarm input‚ an auxiliary output and auto-flip
feature.
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
Synchronisation Internal / Line-Lock;
phase adjustable
Horizontal resolution 480 TV lines
Iris control Auto
S/N ratio > 50 dB
Electronic shutter Auto: 1/1-1/10.000 s
Manual: 22 steps
On-screen display menus (OSD) English
Alarms 4 Alarm in
Gain control AGC
Pan speed 0.1-90°/s
0.1°/s: max. digital zoom
0.4°/s: max. optical zoom
Tilt speed 0.1-45°/s
0.1°/s: max. digital zoom
0.4°/s: max. optical zoom
Preset Speed Pan: max. 400°/s
Tilt: max. 200°/ s
Pan travel Continuous
Tilt travel Indoor: 85°
Outdoor: 92°
Password protection Alphanumerical Dome OSD setup
protection
White balance control ATW (2000-10.000° K)‚ auto (3000-
7500° K); one push
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Presets 64
Privacy zones 8
Programmable patterns 4
Zoom 18 x optical‚ 12 x digital
Lens 4.1-73.8 mm‚ auto focus
Dimensions (Ø x H) 134 x 219.9 mm
Power requirements 20 W
Weight 1.75 kg
