Cameras and Domes
Colour Cameras
1-6 © Siemens Building Technologies Group
Type Order No.
CCBC1225-LP
1/2" DSP Colour Wide Dynamic OSD Camera 480 TVL‚ PAL‚ 12 V DC /
24 V AC
High resolution 1/2" colour camera with advanced features including
49-zone programmable back-light compensation‚ wide dynamic‚ peak-
white inversion and adjustable electronic shutter‚ ensuring the best
images all the time. The camera includes a built-in ID system for
addressing (via RS485 or TTL) and setup is via on-screen display menu‚
or via remote setup software. An alarm input triggers up to 4 digital
images‚ stored in the camera and remotely accessible. Supplied with
operation and parameterisation software.
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
Synchronisation Internal: crystal
External: line-lock‚ video - or HD/VD
Horizontal resolution 480 TV lines
Minimum illumination 0.11 Lux (F1.2‚ AGC 39 dB) at 50 IRE
S/N ratio > 50 dB
Dynamic range 60 dB
Gain control Selectable (ON/OFF)‚
gain (up to 36 dB)
Electronic shutter Automatic: 1/50 s - 1/100000 s
Fixed: 8 s - 1/30000 s
Off: 1/50 s
Back-light compensation Selectable (ON/OFF)‚
up to 49 windows
Camera titles 24 characters
Lens mount CS (C-mount adapter supplied)
Auto-iris lens control Direct drive or Video drive
Dimensions (W x H x D) 74 x 60 x 125 mm
Power requirements 12 V DC / 24 V AC‚ 50 Hz
Power consumption 5 W
Weight 0.45 kg
2GF1181-8EA
