Siemens CRT

Cameras and Domes
Day-Night Cameras
1-14 © Siemens Building Technologies Group
Type Order No.
CCBS1225-LP
1/2" DSP Day-Night Wide Dynamic OSD Camera 480 TVL‚ PAL‚
12 V DC / 24 V AC
High resolution day-night camera with mechanical infrared cut filter‚
providing crisp aperture corrected and low-smear images 24 hours a
day. In night mode the camera is infrared sensitive and can be used
with infrared illumination. In night mode the camera is infrared sensi-
tive and can be used with infrared illumination. Advanced features
include 49-zone programmable back-light compensation‚ wide dynam-
ic‚ peak-white inversion and adjustable electronic shutter‚ ensuring the
best images all the time. The camera includes a built-in ID system for
addressing (via RS485 or TTL) and setup is via on-screen display menu‚
or via remote setup software. An alarm input triggers up to 4 digital
images‚ stored in the camera and remotely accessible. Supplied with
operation and parameterisation software.
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
Synchronisation Internal: crystal
External: line-lock‚ video - or HD/VD
Horizontal resolution 480 TV lines
Minimum illumination Colour mode: 0.045 Lux
(F1.2‚ AGC 39 dB) at 50 IRE
Mono: 0.008 Lux
(F1.2‚ AGC 39 dB) at 50 IRE
S/N ratio >50 dB
Dynamic range 60 dB
Gain control Selectable (ON/OFF)‚
gain (up to 36 dB)
White balance control Manual / auto
Back-light compensation Selectable (ON/OFF);
up to 49 windows
Infrared sensitive 880 nm‚ monochrome mode
Camera titles 24 characters
Lens mount CS (C-mount adapter supplied)
Auto-iris lens control Direct drive or Video drive
Dimensions (W x H x D) 74 x 60 x 125 mm
Power requirements 12 V DC / 24 V AC‚ 50 Hz
Power consumption 5 W
Weight 0.45 kg
2GF1118-8EA
