Siemens CRT

Cameras and Domes
Day-Night Cameras
1-15© Siemens Building Technologies Group
1
Type Order No.
CCBS1337..
1/3" DSP Day-Night OSD Camera 540 TVL
CCBS1337 is a super high resolution day-night camera using the latest
CCD technology and advanced digital signal processing techniques to
provide crisp‚ aperture corrected images for surveillance applications
requiring the highest resolution images. This camera has a mechanical
infrared cut filter‚ providing crisp aperture corrected and low-smear
images 24 hours a day. In night mode the camera is infrared sensitive
and can be used with infrared illumination.
Television standard PAL: 625 lines‚ 50 fields/s‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
Horizontal resolution 540 TV lines
Minimum illumination Colour mode: 0.4 Lux
(F1.4‚ AGC 30 dB) at 50 IRE
Mono: 0.08 Lux
(F1.4‚ AGC 30 dB) at 50 IRE
S/N ratio > 50 dB
Gain control Selectable (ON/TURBO/OFF)‚
gain up to 30 dB
Electronic shutter Automatic: 1/50 s - 1/100000 s
Manual: 1/50 s ... 1 / 10000 s
selectable
Off: 1/50 s
White balance control Manual / auto / one push
Back-light compensation 6 windows selectable: center 1‚
center 2‚ up half‚ low half‚ door low‚
door high
Camera titles 16 characters
Infrared sensitive 880 nm‚ monochrome mode
Lens mount CS (C-mount adapter supplied)
Auto-iris lens control Direct drive or Video drive
Gamma 0.45 / 1.0 selectable
Image sensor 1/3-inch interline CCD
Tripod thread A(1/4)‚ 1/4 inch on bottom and top
Dimensions (W x H x D) 72 x 63 x 122 mm
Power consumption 5 W‚ 8 W (incl. IR-cut filter move-
ment)
CCBS1337..
CCBS1337-LP
1/3" DSP Day-Night OSD Camera 540 TVL‚ PAL‚ 12 V DC / 24 V AC
As CCBS1337.. for technical details‚ but with the following differences:
Power requirements 12 V DC / 24 V AC‚ 50 Hz
Weight 0.45 kg
2GF1118-8FA
CCBS1337-MP
1/3" DSP Day-Night OSD Camera 540 TVL‚ PAL‚ 90 V AC D 260 V AC
As CCBS1337.. for technical details‚ but with the following differences:
Power requirements 90 V AC D 260 V AC‚ 50 Hz
Weight 0.55 kg
2GF1118-8FB
