Siemens CRT

Cameras and Domes
Day-Night Cameras
1-16 © Siemens Building Technologies Group
Type Order No.
CCWC1335..
1/3" DSP Day-Night‚ Wide Dynamic OSD Camera 480 TVL
CCWC1337 is a high resolution Wide Dynamic colour camera using the
latest CCD technology and advanced digital signal processing tech-
niques to provide crisp‚ aperture corrected images for surveillance
applications requiring the highest resolution images. The use of wide
dynamic technology ensures clear viewing in any bright back-lit scenes.
This camera has a mechanical infrared cut filter‚ providing crisp aper-
ture corrected‚ low-smear images 24 hours a day. In night mode the
camera is infrared sensitive and should be used with infrared illumina-
tion.
Television standard PAL: 625 lines‚ 50 fields/s‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
Horizontal resolution > 480 TV lines
Minimum illumination Colour: 0.4 Lux
(F1.4‚ AGC 30 dB) at 50 IRE
Mono: 0.08 Lux
(F1.4‚ AGC 30 dB) at 50 IRE
S/N ratio > 50 dB
Dynamic range 60 dB
Gain control Selectable (ON/TURBO/OFF)‚
gain up to 30 dB
Electronic shutter Automatic: between 1/50 and
1/100‚000 sec
Manual: 1/50s‚ 1/120‚ 1/250‚ 1/400‚
1/1K‚ 1/2K‚ 1/5K‚ 1/10K
White balance control Manual / auto / one push
Back-light compensation 6 windows selectable: center 1‚
center 2‚ up half‚ low half‚ door low‚
door high
Camera titles 16 characters
Infrared sensitive 880 nm‚ monochrome mode
Lens mount CS (C-mount adapter supplied)
Auto-iris lens control Direct drive or Video drive
Gamma 0.45 / 1.0 selectable
Image sensor 1/3-inch interline CCD
Tripod thread A(1/4)‚ 1/4 inch on bottom and top
Dimensions (W x H x D) 72 x 63 x 122 mm
Power consumption 5 W‚ 8 W (incl. IR-cut filter move-
ment)
CCWC1335..
CCWC1335-LP
1/3" DSP Day-Night‚ Wide Dynamic OSD Camera 480 TVL‚ 12 V DC /
24 V AC
As CCWC1335.. for technical details‚ but with the following differences:
Power requirements 12 V DC / 24 V AC‚ 50 Hz
Weight 0.45 kg
2GF1183-8FC
CCWC1335-MP
1/3" DSP Day-Night‚ Wide Dynamic OSD Camera 480 TVL‚ 90 V AC D
260 V AC
As CCWC1335.. for technical details‚ but with the following differences:
Power requirements 90 V AC to 260 V AC‚ 50 Hz
Weight 0.55 kg
2GF1183-8FB
