Cameras and Domes
Day-Night Cameras
1-17© Siemens Building Technologies Group
1
Type Order No.
CCBS1345..
1/3" DSP High Resolution DIP Switch Day-Night Camera
CCBS1345 is equipped with a mechanical IR filter that provides good
picture quality 24 hours a day in colour and monochrome mode. The
switch-over from colour to monochrome can be performed automati-
cally depending on ambient light conditions (3 levels selectable) or by
an external signal using the switch input of the camera.
Television standard PAL: 625 lines‚ 50 fields/s‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Horizontal resolution 480 TVL colour / 540 TVL Mono TV
lines
Minimum illumination Colour: 0.3 Lux @ F=1.4
(AGC 30 dB‚ 50IRE Video Output)
Mono: 0.08 Lux @ F=1.4
(AGC 30 dB‚ 50IRE Video Output)
S/N ratio > 50 dB
Electronic shutter On: Automatic between 1/50 and
1/100‚000 sec
Off: 1/50 s
Back-light compensation Selectable (ON/OFF)
Gamma 0.45
Image sensor 1/3-inch interline CCD‚ 752 x 582
active pixels
Tripod thread A (1/4); 1/4 inch on bottom and top
Dimensions (W x H x D) 72 x 63 x 122 mm
CCBS1345..
CCBS1345-LP
1/3" DSP High Resolution DIP Switch Day-Night Camera,
480 TVL‚ PAL‚ 12 V DC / 24 V AC‚ 50 Hz
As CCBS1345.. for technical details‚ but with the following differences:
Power requirements 12 V DC / 24 V AC
Power consumption 4 W
Weight 0.45 kg
2GF1118-8GA
CCBS1345-MP
1/3" DSP High Resolution DIP Switch Day-Night Camera,
480 TVL‚ PAL‚ 90 D 260 V AC‚ 50 Hz
As CCBS1345.. for technical details‚ but with the following differences:
Power requirements 100 D 240 V AC ± 10%
Power consumption 4.5 W
Weight 0.55 kg
2GF1118-8GB
