Cameras and Domes
Day-Night Cameras
1-18 © Siemens Building Technologies Group
Type Order No.
CCAS1415-LPO
1/4" CCD High Resolution Day-Night OSD Camera PAL‚
Outdoor Use‚ 480 TVL‚ 22x Optical Zoom‚ Auto Focus‚
12 V DC / 24 V AC
The CCAS1415-LPO is a high resolution (480/530 TVL) day-night cam-
era with built-in auto focus zoom lens with max. 242 x zoom. The cam-
era is designed for outdoor use under variable lighting conditions. It is
built into a compact and attractively styled weatherproof housing with
sunshade incorporated. As a result of the day-night function‚ the cam-
era offers optimum picture quality both under varying daylight condi-
tions and also when used at night with infrared light.
Television standard PAL: 625 lines‚ 50 fields/s‚ 50 Hz
(vertically)‚
15.625 Hz (horizontally)
Pixels 795 (H) x 596 (V)
Image sensor 1/4" SONY Super HAD CCD
Synchronisation Internal/external (Line Lock)
Horizontal resolution 480 TV lines
Minimum illumination Colour: 0.5 lux @ F=1.6
(AGC on‚ 50 IRE video output)
Mono: 0.5 lux
Slow-Shutter: 0.001 lux
Zoom Optical zoom x22‚ digital zoom x11
(video AF)
Focal length 3.9 D 85.8 mm
Maximum relative aperture F1.6 (wide) D F3.7 (tele)
Slow speed shutter x 2 D x 60
S/N ratio 52 dB (AGC off)
Operating temperature range -10° C to +50° C
Dimensions (W x H x D) 120 x 120 x 185 mm
Power consumption 9 W
Weight 1.50 kg
2GF1182-8AJ
