Cameras and Domes
Monochrome Cameras
1-4 © Siemens Building Technologies Group
Type Order No.
CCBB1225-LC
1/2" DSP Monochrome Wide Dynamic OSD Camera 580 TVL‚ CCIR‚
12 V DC / 24 V AC
High resolution 1/2" monochrome camera including all features of the
newest camera and chip technology with improved infrared sensitivity.
Advanced features include 49-zone programmable back-light compen-
sation‚ wide dynamic‚ peak-white inversion and adjustable electronic
shutter‚ ensuring the best images all the time. The camera includes a
built-in ID system for addressing (via RS485 or TTL) and setup is via on-
screen display menu‚ or via remote setup software. An alarm input trig-
gers up to 4 digital images‚ stored in the camera and remotely accessi-
ble. Supplied with operation and parameterisation software.
Television standard CCIR: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
Synchronisation Internal: crystal
External: line-lock‚ video - or HD/VD
Horizontal resolution 580 TV lines
Minimum illumination 0.0037 Lux
(F1.2‚ AGC 39 dB) at 50 IRE
S/N ratio > 50 dB
Dynamic range 60 dB
Gain control Selectable (ON/OFF)‚
gain (up to 36 dB)
Electronic shutter Automatic: 1/50 s - 1/100000 s
Fixed: 8 s - 1/30000 s
Off: 1/50 s
Infrared sensitive Up to 880 nm
Back-light compensation Selectable (ON/OFF); up to 49 win-
dows
Camera titles 24 characters
Lens mount CS (C-mount adapter supplied)
Auto-iris lens control Direct drive or Video drive
Dimensions (W x H x D) 74 x 60 x 125 mm
Power requirements 12 V DC / 24 V AC‚ 50 Hz
Power consumption 5 W
Weight 0.40 kg
2GF1081-8EA
