Siemens CRT

Lenses
Varifocal Length Lenses
2-6 © Siemens Building Technologies Group
Type Order No.
CLVD13..
Auto-Iris‚ Direct Drive
Lens with high-performance glass optics for compact size‚ galvanomet-
ric direct‚ drive auto-iris mechanism. Focal length and focus adjust-
ments have screw-locks to ensure views remain as initially set. Supplied
with fitted plug.
The technical details of these lenses are listed below:
CLVD13..
CLVD1314/3.5-8
3.5 D 8 mm F1.4 1/3" CS
Format 1/3" CS-mount
Focal length 3.5 D 8 mm
Focus type Adjustable
Horizontal angle of view 35 D 73.8°
Minimum object distance 0.3 m
Weight 0.0766 kg
2GF1667-8AJ
CLVD1314/2.5-10
2.5 D 10 mm F1.4 1/3'' CS
Format 1/3" CS-mount
Focal length 2.5 D 10 mm
Focus type Adjustable
Horizontal angle of view 28.3 D 105.8°
Minimum object distance 0.3 m
Weight 0.0805 kg
2GF1667-8AM
CLVD1325/5-50
Auto-Iris‚ Direct Drive
Focal length 5 D 50 mm
Focus type Adjustable
Maximum relative aperture F1.4 D C
Horizontal angle of view 5.6 D 53.6°
Minimum object distance 0.3 m
Weight 0.20 kg
2GF1667-8AU
CLVD1318/7-70
7 D 70 mm F1.8 1/3" CS
Format 1/3" CS-mount
Focal length 7 D 70 mm
Focus type Adjustable
Aperture
Horizontal angle of view 4.2 D 40.1°
Minimum object distance 0.3 D 1.0 m
Weight 0.2015 kg
2GF1667-8AL
