Pan/Tilt and Telemetry Equipment
Pan/Tilt Heads
4-5© Siemens Building Technologies Group
4
Type Order No.
P25T-P/L
P25T-P/L Pan & Tilt head‚ 24 V AC
A robust‚ high-performance over-the-top mount AC Pan-Tilt unit (side
mount optional). Allows reliable and accurate control of medium-heavy
loads from 16 to 25 kg‚ with thermostatic heater and heavy-duty pre-
sets as standard. Includes pre-wired cables (2 m long).
Power requirements 24 V AC
Colour Painted Polyester Powdercoat
RAL7032 Leatherette Full Gloss
Dimensions (W x H x D) Side mount:
380 x 230 x 184 mm
Over the top mount:
221 x 252 x 184 mm
Plug connection 7-pin plug (power supply)
4-pin plug (presets)
Pan speed 6°/s
Tilt speed 3°/s
Load rating 16 kg (Over the Top) or
25 kg (Side mount)
Potentiometer on both axis yes
Presets Yes
Protection rating IP66
Weight 7.0 kg
BPZ:80-352
P25T-P
P25T-P Pan & Tilt head‚ 230 V AC
A robust‚ high-performance over-the-top mount AC Pan-Tilt unit (side
mount optional). Allows reliable and accurate control of medium-heavy
loads from 16 to 25 kg‚ with thermostatic heater and heavy-duty pre-
sets as standard. Includes pre-wired cables (2 m long).
Power requirements 230 V AC
Colour Painted Polyester Powdercoat
RAL7032 Leatherette Full Gloss
Dimensions (W x H x D) Side mount:
380 x 230 x 184 mm
Over the top mount:
221 x 252 x 184 mm
Plug connection 7-pin plug (power supply)
4-pin plug (presets)
Pan speed 6°/s
Tilt speed 12°/s
Load rating 16 kg (Over the Top) or
25 kg (Side mount)
Potentiometer on both axis yes
Presets Yes
Protection rating IP66
Weight 7.0 kg
BPZ:80-351
