Siemens CRT

Matrix Switching Systems
Matrix Switchers
10-5© Siemens Building Technologies Group
10
Type Order No.
SIMNEO OM
SIMATRIX NEO Main Chassis Extension Module for 8 Monitor
Outputs
Output module to expand the SIMATRIX NEO SIMNEO-168 by 8 video
outputs with text overlay/OSD (max 32 video outputs).
Weight 0.03 kg
2GF2211-8DA
SIMNEO SOM
SIMATRIX NEO Extension Chassis Extension Module for 8 Monitor
Outputs
Output module to expand the SIMATRIX NEO SIMNEO-EXT by 8 video
outputs without text overlay/OSD (max 32 video outputs).
2GF2211-8DB
SIMNEO A128
Alarm Box Incl. 128 Alarm Inputs
Alarm box for expansion of the SIMATRIX NEO alarm inputs in steps‚
128 Alarm-Inputs in 19"-Rack Device‚ 1 HU
Alarm inputs 128 x
Interfaces SysLink for communication with
SIMNEO-168
Design 19-inch rack mountable; 1U
Power requirements 115 D 230 V AC‚ Tolerance: +10 % to
-15 %‚ 50-60 Hz switchable
Dimensions (W x H x D) 449 x 44 x 206 mm
Weight 2.50 kg
2GF2211-8EA
SIMATRIXNEO-EXP168
SIMATRIX NEO Matrix Extension Bay 32x16‚ Expandable
Extension chassis for the SIMATRIX NEO‚ including 32 camera inputs
and 16 monitor outputs for connection to SIMNEO-168 master chassis.
Connection to the basic chassis via 1x RS485 high-speed asynchronous‚
internal (maximum 1 extension chassis).
Camera inputs 32 x BNC video in‚ 1Vpp‚ 75 Ohm‚
max 240 with SIMNEO168
Design 19-inch rack mountable; 6 HU
Monitor output 16 x BNC‚ 1 Vpp‚ 75 Ohm‚ max 32
with SIMNEO-SOM
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Interfaces SysLink for communication with
SIMNEO-168
Television standard PAL/CCIR
Power requirements 115 D 230 V AC‚ 50-60 Hz
Weight 6.30 kg
2GF2211-8AB
