Cameras and Domes
Colour Cameras
1-10 © Siemens Building Technologies Group
Type Order No.
CCBC1345..
1/3" DSP Colour DIP Switch Camera 480 TVL
CCBC1345 is a high resolution colour camera using the latest CCD tech-
nology and advanced digital signal processing techniques to provide
crisp‚ aperture corrected images for surveillance applications requiring
high resolution images. Setup is via DIP switches.
Television standard PAL: 625 lines‚ 50 fields/s‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Synchronisation Internal: crystal
External: Line-lock
Pixels 752 (H) x 582 (V)
Horizontal resolution 480 TV lines
Minimum illumination 0.6 Lux (F1.2‚ AGC 38 dB) at 50 IRE
S/N ratio > 50 dB
Gain control Max 38 dB
White balance control Auto
Back-light compensation Selectable (ON/OFF)
Lens mount CS (C-mount adapter supplied)
Auto-iris lens control Direct drive or Video drive
Electronic shutter Automatic: 1/50 s - 1/100000 s
Off: 1/50 s
Dimensions (W x H x D) 72 x 63 x 122 mm
Power consumption 4 W
CCBC1345..
CCBC1345-LP
1/3" DSP Colour DIP Switch Camera 480 TVL‚ PAL‚ 12 V DC / 24 V AC
As CCBC1345.. for technical details‚ but with the following differences:
Power requirements 12 V DC / 24 V AC‚ 50 Hz
Weight 0.45 kg
2GF1183-8GA
CCBC1345-MP
1/3" DSP Colour DIP Switch Camera 480 TVL‚ PAL‚ 90 V AC D 260 V AC
As CCBC1345.. for technical details‚ but with the following differences:
Power requirements 90 V AC / 24 V AC‚ 50 Hz
Weight 0.55 kg
2GF1183-8GB
CCBC1345-LN
1/3" DSP Colour DIP Switch Camera 480 TVL‚ NTSC‚ 12 V DC / 24 V AC
As CCBC1345.. for technical details‚ but with the following differences:
Television standard NTSC: 525 lines‚ 60 fields‚
60 Hz (vertically)‚
15‚734 Hz (horizontally)
Pixels 768 (H) x 494 (V)
Electronic shutter Automatic: 1/60 s - 1/100000 s
Off: 1/60 s
Power requirements 12 V DC / 24 V AC‚ 60 Hz
Weight 0.45 kg
2GF1183-8GC
