Recording Systems
Digital Video Recorders
11-12 © Siemens Building Technologies Group
Type Order No.
MX3216 500/200
Hybrid Video Recording System
As SISTORE MX.. for technical details‚ but with the following
differences:
Recording speed 200 ips (100 ips analogue and 100
ips digital)
Video inputs Analog: 16 x FBAS (composite)‚
1 VSS / 75 Ohm
Digital: 32 IP-camera inputs via net-
work interface
Alarm inputs/outputs 32 / 16
Video inputs 32 digital (IP cameras connected
via network)‚
16 analogue (additional activation
of 2 x 8 analogue inputs possible)
Digital inputs/outputs 8 / 0
Hard disk capacity 500 GB (expandable)
Monitor output 1 x VGA‚ 4 x BNC
Weight 11.00 kg
S24245-F5085-A4
MX3232 1000/200
Hybrid Video Recording System
As SISTORE MX.. for technical details‚ but with the following
differences:
Recording speed 200 ips (100 ips analogue and 100
ips digital)
Video inputs Analog: 32 x FBAS (composite)‚
1 VSS / 75 Ohm
Digital: 32 IP-camera inputs via net-
work interface
Alarm inputs/outputs 32 / 16
Camera inputs 32 digital (IP cameras connected
via network)‚ 32 analog
Digital inputs/outputs 8 / 0
Hard disk capacity 1000 GB (expandable)
Monitor output 1 x VGA‚ 4 x BNC
Weight 11.00 kg
S24245-F5085-A6
SISTORE MX NVR16
Network Video Recorder‚ 16 IP Cameras‚ 80 GB‚ LAN
SISTORE MX NVR16 is a flexible digital surveillance and video recording
system that allows the live images supplied by IP cameras to be record-
ed. It permits remote surveillance via LAN or ISDN.
Recording speed 100 images per second
Hard disk capacity 80 GB
Interfaces 4 x USB 2.0 high speed/high current‚
2 x Ethernet port (RJ45)‚ 1 x LAN
Operating temperature range +5 to +40 °C
Power consumption max. 4 A (at 24 V)
Power requirements 24 V DC (20.4 to 28.8 V)
Dimensions (W x H x D) 262 x 133 x 47 mm
Weight max. 2.0 kg
S24245-F5086-A3
