Siemens CRT

Recording Systems
Network Video
11-17© Siemens Building Technologies Group
11
Type Order No.
SISTORE CX..
Intelligent Digital Video Codec
SISTORE CX is an intelligent digital video CODEC capable of performing
multiple tasks simultaneously over a network. Utilising MPEG-4 SP/ASP‚
SISTORE CX offers incredible performance in both transmission speed‚
image quality and detailed video analysis. It provides three operating
modes for real-time video: transmitter (encoding) mode‚ receiver
(decoding) mode or the combination transceiver mode‚ plus recording.
Interfaces 1 x RJ45 - Ethernet (10baseT‚
100baseT)
1 x RS485
1 x RS232
Video (in/out) CX1:
1 input / 1 output
CX4:
4 inputs / 0 output
2 inputs / 1 output
1 input / 1 output
0 input / 2 outputs
CX8:
8 inputs / 0 output
4 inputs / 2 output
2 input / 2 output
0 input / 4 outputs
Video inputs BNC with loop-through (75 Ohm)
(see inputs/outputs for configura-
tions)
Video outputs BNC (75 Ohm)
(see inputs/outputs for configura-
tions)
SISTORE CX..
CX1 0/25
Intelligent Digital Video Codec‚ 1 Camera‚ 25 ips
As SISTORE CX.. for technical details‚ but with the following differences:
SISTORE CX is an intelligent digital video CODEC capable of performing
multiple tasks simultaneously over a network. Utilising MPEG4 SP/ASP‚
SISTORE CX offers incredible performance in both transmission speed‚
image quality and detailed video analysis. It provides three operating
modes for real-time video: transmitter (encoding) mode‚ receiver
(decoding) mode or the combination transceiver mode‚ plus recording.
Compression MPEG-4 SP/ASP
Hard disk capacity None (1 slot available for compact
flash card)
Digital inputs 2
Digital outputs 2
Interfaces 1 x RJ45 - Ethernet (10baseT‚
100baseT)
1 x RS485
Recording speed 25 ips encoding (CIF‚ 2CIF‚ 4CIF)
25 ips decoding (CIF‚ 2CIF‚ 4CIF)
Power consumption 15 W
Power requirements 12 D 24 V DC or 24 V AC‚ max. 1.25 A
Weight 0.95 kg
S24245-F5104-A1
