Solaris™ Colour High-Speed Dome
Solaris™ offers accuracy‚ speed‚ reliability and high quality images. With
its unique split concept‚ External Termination Unit (XTU) and camera
Head Unit (HU)‚ Solaris™ has proven to be the solution of choice for
installers and end-users around the world.
From shops to holiday resorts‚ hospitals to commercial premises‚ with
perfect picture quality‚ Solaris™ ensures security is kept at its highest.
These new developments in dome technology now bring you more fea-
tures than ever before.
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Horizontal resolution 480 TV lines
S/N ratio M 50 dB
Electronic shutter 1/10000 s‚ 22 steps
Gain control Auto (-3 to 28 dB‚ 2 dB steps)
Pan speed 0.2 D 360°/sec
Tilt speed 0.2 D 360°/sec
Pan travel 360° continuous
Tilt travel +10° and -100°
White balance control Auto/One Push
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Presets Max. 99 (depending on protocol
and controller)
Dimensions (Ø x H) 245 x 354 mm
Power requirements 18 D 24 V DC @ 2 A‚ supplied from
the XTU via the Cat-5 cable
CCDS1415..
CCDS1415-ST
Solaris™ 1/4" High-Speed Dome‚ 24 Privacy Zones‚ 18x Zoom‚ Col-
our‚ Smoked Bubble‚ IP67‚ Supplied with 110 D 230 V AC XTU
As CCDS1415.. for technical details‚ but with the following differences:
Minimum illumination 0.05 lux
Lens 18 x optical‚ 12 x digital
4.1 to 73.8 mm (F1.4 to F3.0)
Weight 5.6 kg
2GF1194-8AA
CCDS1415-DN
Solaris™ 1/4" High-Speed Dome‚ 24 Privacy Zones‚ x18 Zoom‚ Day-
Night‚ Clear Bubble‚ IP67‚ Supplied with 110 D 230 V AC XTU
As CCDS1415.. for technical details‚ but with the following differences:
Minimum illumination 0.05 lux (colour)
0.01 lux (mono)
Lens 18 x optical‚ 12 x digital
4.1 to 73.8 mm (F1.4 to F3.0)
Weight 5.6 kg
2GF1194-8AC
