Cameras and Domes
Dome Mounts and Accessories
1-42 © Siemens Building Technologies Group
Type Order No.
CVVA-FMIP
Indoor Flush Mount for Usage with Indoor Dome Series CFxx and
Vandal Dome Series CVxx with or without Optional IP Modules
CFVA-IP or CVVA-IP.
This indoor‚ flush ceiling-mount includes a clear bubble that will pre-
vent the ingress of dust when the indoor domes CFxx or vandal domes
CVxx are installed indoors. It is suitable for mounting with or without
the optional IP modules CFVA-IP or CVVA-IP. The flush mount enables
the indoor dome series CFxx and vandal dome series CVxx to be
recessed into a hole cut into the ceiling.
Dimensions (Ø x H) 225 x 120 mm
Weight 1.30 kg
2GF1086-8AM
CVVA-WMIP
Wall Bracket for Usage with Vandal Dome Series CVxx with or with-
out Optional IP Module CVVA-IP
This wall mount attaches directly to a flat upright wall. It enables a
mount of the vandal dome series with or without the optional IP mod-
ule CVVA-IP.
Weight 0.50 kg
2GF1086-8AN
CFVA-BA
Indoor Dome Base CFVA-BA
The dome base provides additional installation space to hide the ca-
bling inside the base. It is is only designed for installation indoors and
only for use in conjunction with following dome camera: CFFB1310‚
CFFB1315‚ CFFC1310‚ CFFC1315‚ CFVB1415‚ CFVC1415 and
CFVS1415.
Additionally‚ the indoor dome base supports the installation of an
optional twisted pair transmitter module CTTT0111 (2GF1714-8WN).
When the twisted pair transmitter is used‚ the unit including the dome
camera can be used with operation voltage of 12 V DC only!
Dimensions (Ø x H) 140 x 35.3 mm
Weight 0.40 kg
2GF1086-8AP
