Siemens CRT

Lenses
Fixed Focal Length Lenses
2-3© Siemens Building Technologies Group
2
Type Order No.
CLFM1312/8
8.0 mm F1.2‚ 1/3" CS
Focal length 8.0 mm
Maximum relative aperture F1.2
Horizontal angle of view 36.5º
Minimum object distance 0.3 m
Focus type Adjustable
Format 1/3" CS-mount
Weight 0.0411 kg
2GF1661-8AP
CLFM1316/16
16 mm F1.6‚ 1/3" CS
Focal length 16.0 mm
Maximum relative aperture F1.6
Horizontal angle of view 17.6°
Minimum object distance 0.7 m
Focus type Adjustable
Format 1/3" CS-mount
Weight 0.0395 kg
2GF1661-8AQ
CLFD13..
Auto-Iris‚ Direct Drive
Lens with high-performance glass optics‚ galvanometric direct drive‚
auto-iris mechanism and ND spot-filter - ideal for outdoor applications.
Screw lock ensures images remain sharply focused. Supplied with fitted
plug.
The technical details of these lenses are listed below:
CLFD13..
CLFD1214/12
12.0 mm F1.4‚ 1/2" C
Focal length 12.0 mm
Focus type Adjustable
Maximum relative aperture F1.4
Horizontal angle of view 29.7°
Minimum object distance 0.2 m
Format 1/2" C-mount
Weight 0.0825 kg
2GF1642-8AT
CLFD1314/2.8
2.8 mm F1.4‚ 1/3" CS
Focal length 2.8 mm
Maximum relative aperture F1.4
Horizontal angle of view 95.6º
Minimum object distance 0.2 m
Format 1/3" CS-mount
Weight 0.0633 kg
2GF1663-8AN
