Siemens CRT

Housings and Mounts
Outdoor Housings
3-5© Siemens Building Technologies Group
3
Type Order No.
HS01/L
Large Connoisseur Housing 24 V AC
Ideal for most applications‚ especially for larger length cameras and
lenses. Suitable for outdoor use. Extruded aluminium section construc-
tion. Sunshield is adjustable along the length of the housing body.
Hinge retained body allows easy access for maintenance. Adjustable
mounting plate to suit most camera/lens assemblies. Demister & sun-
shield fitted as standard‚ optional wiper available.
Power requirements 24 V AC‚ 50/60 Hz
Colour Housing body: Polyester powder-
coat RAL7032 leatherette full gloss.
Sunshield: Polyester powdercoat
hipca white smooth full gloss.
Dimensions (W x H x D) Housing: 155 x 148 x 627 mm
Sunshield: 560 x 168 mm
Usable volume (W x H x D) 125 x 100 x 400 mm
Finish Aluminium extrusion (housing body
& sunshield)‚ glass filled polyester
thermoset (front & rear caps)
Heater turn-on 14 °C
Heater turn-off 20 °C
Heater rating 7 W nominal‚ 25 W max. PTC resistor
heating element.
Protection rating IP66
Weight 6.0 kg
BPZ:80-143
HS02
Compact Connoisseur 230 V AC
An addition to the Connoisseur range‚ the Compact Connoisseur offers
attractive styling with attractive features. Enables mounting with a
bracket or with pan/tilt heads.
Power requirements 230 V AC ‚ 50/60 Hz
Colour Housing Body: Polyester Powder-
coat RAL7032 Leatherette Full
Gloss.
Sunshield: Polyester Powdercoat
Hipca White Full Gloss.
Cable entry 2 x M16
1 x PG 13‚5
Dimensions (W x H x D) Housing: 133 x 125 x 454 mm
Usable volume (W x H x D) 85 x 80 x 225 mm
Finish Pressure die-cast aluminium with
extruded aluminium body and sun-
shield.
Heater turn-on 14 °C
Heater turn-off 20 °C
Heater rating 7 W nominal‚ 25 W max. PTC resistor
heating element.
Protection rating IP67
Weight 2.52 kg
BPZ:80-148
